The Absolyte® GX is part of the proven Absolyte® history dating back to 1983 when we debuted the first large-capacity VRLA battery in the industry.
Design life in years: 20 @ 25°C
Nominal capacity: 2000–6000 Ah @ 25°C
Grid plate
Single cell
Valve regulated lead-acid batteries
Maintenance-free (no topping-up)
Special high current performance
Recyclable
- System Ampere-hour Range: 2000 to 6000 Ah to 1.75 VPC at 8 hour rate
- Container and Cover. Flame Retardant Polypropylene standard (UL94 V-0/28% L.O.I)
- Positive Plate: Patented Lead-Calcium-Tin-Silver positive grid
- Negative Plate: Lead Calcium grid alloy
- Separator: Absorbent glass mat (AGM)
- Electrolyte: 1.295 Specific Gravity Acid
- Terminals: Solid Copper
- Safety Vent: 3-10 psi opening pressure, self resealing
- Container to Cover Seal: Polypropylene to polypropylene fusion bond
- Post to Cover Seal: Polypropylene to polypropylene fusion bond
- Float Voltage: 2.23 to 2.25 VPC
- Design Life: 20 years in float service at 25°C (77°F)
- Cycle Life: 1200 cycles to 80%DOD at 25°C (77°F)
- Operating Temperature: Temperature excursions between -40°C (-40°F) to +50°C (122°F) allowed (Battery performance and life will be affected)
- Enhanced post access for maintenance and battery health assessment
