• Inverter/Chargers: Off-Grid


    Solar. Wind. Hydro. Generator. No matter what your energy source OutBack's products are engineered to provide your home or business with reliable electricity day-in and day-out. The OutBack modular system architecture allows your system to grow along with your power needs up to 36,000 watts. Power hungry appliances like washing machines, air conditioning and power tools are easily started by our inverter's substantial surge power capability. When not being used, the inverter enters a power save mode, which consumes as little as 3 watts, saving your battery power for when you need it the most.

    OutBack's innovative Maximum Power Point Tracking (MPPT) technology gets the most from your solar array or can also control hydro or wind turbine charging sources. Complete system status and control is easily monitored by a single control, instead of requiring the user to keep an eye on multiple displays and status indicators.


    Contact Sigma Communications Ltd. for this Product.


    Technical Specifications
    Sealed Models Vented Models
    FX2012T FX2524T FX3048T VFX2812 VFX3524 VFX3648
    Nominal DC Input Voltage 12 VDC 24 VDC 48 VDC 12 VDC 24 VDC 48 VDC
    Continuous Power Rating at 25° C 2000 VA 2500 VA 3000 VA 2800 VA 3500 VA 3600 VA
    AC Voltage/Frequency 120 VAC 60 Hz 120 VAC 60 Hz 120 VAC 60 Hz 120 VAC 60 Hz 120 VAC 60 Hz 120 VAC 60 Hz
    Continuous AC RMS Output at 25° C 17.0 amps AC 20.8 amps AC 25.0 amps AC 23.3 amps AC 29.2 amps AC 30.0 amps AC
    Full Idle Power ≈ 20 Watts ≈ 20 Watts ≈ 23 Watts ≈ 20 Watts ≈ 20 Watts ≈ 23 Watts
    Search ≈ 6 Watts ≈ 6 Watts ≈ 6 Watts ≈ 6 Watts ≈ 6 Watts ≈ 6 Watts
    Typical Efficiency 90% 92% 93% 90% 92% 93%
    Typical Total Harmonic Distortion 2% 2% 2% 2% 2% 2%
    Maximum 5% 5% 5% 5% 5% 5%
    Output Voltage Regulation ± 2% ± 2% ± 2% ± 2% ± 2% ± 2%
    Peak Maximum Output Current 56 amps AC 70 amps AC 70 amps AC 56 amps AC 70 amps AC 70 amps AC
    RMS 40 amps AC 50 amps AC 50 amps AC 40 amps AC 50 amps AC 50 amps AC
    Surge AC Overload Capability 4800 VA 6000 VA 6000 VA 4800 VA 6000 VA 6000 VA
    5 Second 4000 VA 4800 VA 4800 VA 4000 VA 5000 VA 5000 VA
    30 Minutes 2500 VA 3200 VA 3200 VA 3200 VA 4000 VA 4000 VA
    AC Input Current Maximum 60 amps AC 60 amps AC 60 amps AC 60 amps AC 60 amps AC 60 amps AC
    AC Input Voltage Range (MATE Adjustable) 80 to 150 VAC 80 to 150 VAC 80 to 150 VAC 80 to 150 VAC 80 to 150 VAC 80 to 150 VAC
    AC Input Frequency Range 54 to 66 Hz 54 to 66 Hz 54 to 66 Hz 54 to 66 Hz 54 to 66 Hz 54 to 66 Hz
    DC Input Voltage Range 10.5 to 17.5 VDC 21.0 to 34.0 VDC 42.0 to 68.0 VDC 10.5 to 17.0 VDC 21.0 to 34.0 VDC 42.0 to 68.0 VDC
    Continuous Battery Charge Output 80 amps DC 55 amps DC 35 amps DC 125 amps DC 85 amps DC 45 amps DC
    Warranty Standard 2 year / Optional 5 year Standard 2 year / Optional 5 year
    Unit Weight 56 lbs (25 kg) 54 lbs (25 kg)
    Shipping 67 lbs (30 kg) 62.2 lbs (28 kg)
    Unit Dimensions (H x W x L) 13 x 8.25 x 16.25" (33 x 21 x 41 cm) 12 x 8.25 x 16.25" (30 x 21 x 41 cm)
    Shipping 21.75 x 13 x 22" (55 x 33 x 56 cm) 21.75 x 13 x 22" (55 x 33 x 56 cm)
