Pure IP-PBX: KX-TDE200BX
  • Initial system accepts up to 64 IP-proprietary telephones and 32 IP-trunks with the optional DSP card
  • SIP phones accept up to 128 standard
  • 2 Built-in LAN ports
  • Support the new IP-PT KX-NT300 Series
  • Full support of KX-TDA features
  • Upgradeable to KX-TDE by changing the main card (IPCMPR) in the KX-TDA
  • Multi-site programming

    • Server Connection

  • DHCP client for KX-TDE
  • SNMP Agent / Alarm
  • SNTP client


  • Built-in simplified voice message
  • Enhanced walking extension (Hot desking)
    • Product Specifications
    Type
    Total Number of Trunks 128
    Trunk with option card 128
    IP Trunk on MPR card 64*1
    H.323 trunks 32
    SIP trunks 32
    Terminal Equipment Type
    Telephone 256
    SLT 128
    KX-DT300 / KX-T7600series DPT 256
    Other DPT 128
    APT 24
    IP-PT 192
    IP-PT*2 (supported by IP-EXT16card) 128
    IP-PT*3 (supported by MPRcard) 128
    SIP Extension 128
    DSS console 8
    CS 32
    High-density CS 16
    IP-CS 16
    PS 128
    Voice Processing System (VPS)*4 2
    Doorphone 16
    Door Opener 16
    External Sensor 16
    External Relay 16
