Panasonic Products

100 phone book memory / 10 last dialed number

2.1” Large LCD with white back light on cordless handset

Support for 3 simultaneous network conversations

Compatible with Asterisk and Broadsoft

Low standby power consumption

Programmable ring groups

Up to 6 cordless handsets

Up to 8 SIP registrations

Local or network intercom

HD Voice (G.722) on DECT radio

10 days stand-by and 5 hour talk time

DID on each cordless handset

Wall mounting

Hands-free speaker phone on cordless handset

Plug and Play configuration

VoIP Support
IETF SIP version 2 (RFC3261 and companion RFCs)	Yes
BroadWorks R17 / BroadSoft	Yes
Asterisk^*1	Yes
Voice Codec
G.711a-law / G.711µ-law / G.722 (wideband) / G.729a / G.726 (32K)	Yes
Provisioning
HTTP / HTTPS / FTP / TFTP and Local / Remote WEB Configuration	Yes
QoS Support
DSCP	Yes
Static VLAN	From October 2011
TOS	Yes
Keys and Indications
Menu Driven User Interface	Yes
RF-System
US-DECT 1.92GHz - 1.93GHz (for USA and Canada)	Yes
EU-DECT 1.88GHz - 1.90GHz / GAP	Yes
Phone Features
Multiple Handset	6
Multiple Registration Support	8
2.5mm Headset Jack^*2	Yes
Grouping Handset : Handset Select for Receiving Call	Yes
Handset and Number Select for Making Call	Yes
Redial	Yes
Do Not Disturb	Yes
Anonymous Call (CLIR)	Yes
Anonymous Call Rejection	Yes
Calling Party Name and Number Presentation (CLIP, CNIP)	Yes
Call Rejection	Yes
DTMF Dialing During Call	Yes
3-Party Conferencing	Yes
Call Transfer	Yes
Call Hold	Yes
Call Forward Unconditional / User Busy / No Answer	Yes
Call Waiting	Yes
Distinctive Ringing	Yes
Ringtone Selection	Yes
Interface
Ethernet Ports	1
Ethernet Interface	10/100 Mbps
Battery	630mAh Ni-MH　2 x AAA
Talk Time	Up to 5 hours
Standby Days	Up to 240 hours
Operating Environment	0 °C - 40 °C (32 °F - 104 °F) 20 % - 80 % relative air humidity (dry)
Dimensions
Base unit (Width x Depth x Height; handset on cradle, stand attached)	178 mm x 74.4 mm x 134.4 mm
Weight	Base: 290 g Handset: 130 g Charger: 60 g

Note:

^*1

^*2
